Custom Size Chipboard Screw with Yellow Zinc Plated

Product Content:

This is a Custom Size Chipboard Screw with Yellow Zinc Plated from Qimao Metal Manufacturer designed for engineered wood products. We start with low-carbon steel wire, cold head it into shape, then roll the threads. Rolling, not cutting, gives you threads that are work-hardened and resistant to stripping. The yellow zinc plating goes on after forming—consistent thickness across the head and shank, no pooling in the recess. Comes out a bright golden color that gives a clean finished look on visible joints.

Custom size is what we do regularly. Whatever length you need, we can hit it. Head diameter, thread length, point style—we’ll tweak it to match your assembly jig. We run these on high-speed formers, so lead times stay reasonable. If you’re doing cabinet doors, drawer boxes, or furniture frames, this screw drives fast, holds tight, and leaves a flush finish with a standard Phillips bit. No pre-drilling required for most particle board applications—the self-tapping tip handles it.



Product Specification:

Product Name:	Item No.:	Material:	Measurement(mm):			Surface Finish:	Weight(g):
			L:	W:	Dia:
Custom Size Chipboard Screw with Yellow Zinc Plated	QM1108	Steel	57.8	/	13/4	Yellow Zinc Plated	7.77

Technical Details:

The head on this Custom Size Chipboard Screw with Yellow Zinc Plated screw is a flat countersunk style with a deep Phillips recess. We keep the recess geometry tight—no cam-out issues when you’re running production line speeds. Recess depth is critical, and we check it with go/no-go gauges. The head diameter is consistent across the batch, so every screw seats at the same depth. That matters when you’re using a pneumatic driver set to a specific torque.

Threads are coarse pitch with a sharp crest. This design grabs chipboard fibers without splitting the material. The tip has a self-tapping point with a gentle taper—starts straight, drives smooth, won’t walk on you. Yellow zinc plating is applied in a barrel process, then passivated to lock in the corrosion resistance. Salt spray testing holds up to 48 hours minimum. We also offer a wax or oil lube top coat if you’re driving into dense material and want even less friction.

Core Advantages:

• Custom dimensions available for Custom Size Chipboard Screw with Yellow Zinc Plated– length, head diameter, and thread specs adjusted to your drawing.

• Coarse, sharp threads – bite into particle board and MDF without splitting.

• Self-tapping tip – eliminates pilot holes in most engineered woods, speeds up assembly.

• Flat countersunk head – sits flush with the surface, clean finish on visible joints.

• Deep Phillips recess – reduces bit slip and stripped heads during power driving.

• Yellow zinc plated – 48-hour salt spray resistance for indoor humidity protection.

• Rolled threads – work-hardened flanks resist stripping better than cut threads.

• Lube coating available – wax or oil top coat reduces driving torque on dense boards.

• Consistent batch quality – tight tolerances on head, recess, and thread across every order.

Wide Usage:

1-The Custom Size Chipboard Screw with Yellow Zinc Plated for Kitchen cabinet organize assembly – frames, hinges, back panels etc.

2-Drawer box construction – side, front, and bottom connections.

3-Furniture manufacturing – chairs, tables, shelves, bed frames.

4-MDF and particle board panel joining – edge and surface fastening.

5-Flat-pack and ready-to-assemble furniture units.

6-Shop fixtures, displays, and shelving installations.

7-Door and window frames in engineered wood.

8-Vanity and bathroom cabinets – humidity-resistant joints.

9-Flooring underlayment – plywood and OSB subfloor attachment.

10-Automated production lines – stable performance in screw feeding systems.
